Imported HORIBA analyzer is selected, and the main components are imported products
Accurate wet measurement, continuous measurement of S0 concentration, simultaneous display of NO/NO/NOx, concentration
No need to heat the sampling pipeline
Imported M&C sampling probe and intermediate dilution technology reduce the water content of sample gas and completely eliminate the influence of condensate
Calibration includes full system calibration and local calibration starting from the probe
Dilution technology solves the problem of blockage caused by high dust content in flue gas
Fast sample gas transmission, small maintenance workload and few consumables
The whole process is transmitted under positive pressure, and the local small leakage will not affect the measurement data
Power plant
Steel industry
Cement industry
Petrochemical industry
Paper industry
Biomass thermal power plant
Other industrial process control
TUV suitability test passed
Passed the China National Environmental Protection Certification
Passed China National Metrology Certification
SO2 analyzer: ultraviolet fluorescence method (ppb high-precision analyzer)
NOx analyzer: chemiluminescence method (ppb level high-precision analyzer, simultaneous display and measurement of NO/NO2/NOx)
Dilution probe (external dilution, dilution ratio 100:1, dilution ratio can be customized)
Dilution air prefabrication unit (reliable zero gas generator)
Optional CO and CO2 component measurement
